Auxiliary Lights

Aux LED – LP9 PRO

A design that was inspired by Baja Designs’ legendary 203mm (8″) La Paz HID; The LP9 features modern styling and performance, with some of the most advanced LED technologies available today. The LP9 utilizes 9 forward projecting LEDS to produce 11,025 Lumens at 105 watts, and 6 LEDs for Integrated Peripheral Technology (IPT) which produce 1,140 lumens at 10.5 watts per side. The IPT provides an incredible 200° spread of usable light. The housing was designed to provide exceptional heat dispersion by using Direct Ducted Cooling, which allows air to travel from the front of the housing to the rear. With a day-time running light, low, and high power mode, the LP9 will fulfill all your lighting needs. Available in a standard model that is perfect for a wide range of off-road use, as well as a Racer Edition configuration that is designed for the demands of high speed driving. The Racer Edition has similar power draw, but produces a much tighter pattern, providing higher visibility at greater distances. Both models feature uService technology, which allows customers to change the lens pattern and color depending on driving conditions, or simply when they want to refresh the lens. Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page DATA SHEET Baja Designs Features: uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Color Specifications: Forward Projecting Lumens: 11,025 Utilizing 9 LEDs Forward Projecting Wattage/Amps: 105W / 7.6A IPT Lumens: 2,280 Utilizing 6 LEDs IPT Wattage/Amps: 21W / 1.52A Dimensions: 203mm (8″) Diameter/ 82.5mm (3.25″) Depth Weight: 2948g LED Life Expectancy: 49,930 Hours Front Lens: Hardcoated Polycarbonate Housing: Hard Anodized Machined Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Overvoltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (42°) and the spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) Wiring needed LP9, Harness, 2-light max, Pro (640172) .embed-container { position: relative; padding-bottom: 56.25%; height: 0; overflow: hidden; max-width: 100%; } .embed-container iframe, .embed-container object, .embed-container embed { position: absolute; top: 0; left: 0; width: 100%; height: 100%; }

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – S1

Aux LED 4750 Lu S1 (sports): Designed from the ground up our new S1 fills the shoes of a large light in a small package! The S1 utilizes a highly specialized reflector and LED combination to outshine the competition. With the 53mm (2.1″) length, width, and height the S1 is highly versatile for any application that is in need of light. Whether you’re looking for a light to drive off of, or something to light up a campsite the S1 will exceed your expectations! Baja Designs Features: uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Color Specifications (Per Light): Lumens: 2,320 Utilizing 1 LED Wattage/Amps: 20W / 1.45A Dimensions: 53mm (2.1″) x 53mm (2.1″) x 53mm (2.1″) Weight: 181.4g LED Life Expectancy: 49,930 Hours Front Lens: Hard Coated Polycarbonate Housing: Hard Anodized & Powder Coated Cast Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Overvoltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Includes: S1 LED Light Mounting Bracket (SS for the Light) not the clamps Standard wiring with a pair of lights is included Switch that comes as a standard with the wiring kit .embed-container { position: relative; padding-bottom: 56.25%; height: 0; overflow: hidden; max-width: 100%; } .embed-container iframe, .embed-container object, .embed-container embed { position: absolute; top: 0; left: 0; width: 100%; height: 100%; } Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – S2 PRO

The S2 Pro LED Light offers an incredible 2,450 lumens out of a tiny 76mm (3”) x 50.8mm (2”) housing; the S2 Pro is quite literally the brightest LED light ounce for ounce on the market. The S2 Pro can be mounted where traditional lights would never fit. Moreover, it only draws 24 watts so your electrical system will barely know it’s there. Baja Designs Features: uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Color Specifications: (EACH LIGHT) Lumens: 2,450 Utilizing 2 Cree XM-L2 LEDs Wattage/Amps: 24W / 1.70A Dimensions: 74.4mm x 44.7mm x 42.6mm (2.93″ x 1.76″ x 1.68″) Weight: 226.7g LED Life Expectancy: 49,930 Hours Front Lens: Hard Coated Polycarbonate Housing: Hard Anodized & Powder Coated Cast Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Over voltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Contains: (2) LED Lights LED Holding Brackets (Not Engine bar clamps) Basic Wiring Harness Wiring harness has an inbuilt on/off switch Free 2N Rock Guards (Black) Optional / Additional Upgrade available on request Longer Wiring Harness with Connectors and Push Button Switch Included Brackets 25mm (1″) or 22.2mm (7/8th Inch) ( engine Bar clamps) Included S2 Pro LED Lights Driving Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Cornering(42°) and Spot (9°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) DATA SHEET Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – S2 SPORTS

Aux LED S2 Sports The S2 Sport features the same quality, fit, and finish that is synonymous with the Baja Designs name, at an attractive price point. The S2 Sport is ideal as a fog, cornering, rack, or reverse light and much more. A compact and powerful light, featuring quality that is second to none. When bought as a pair it includes a simple wiring harness included. A basic on off switch ( not handlebar switch). Does not include a relay, diode etc. Baja Designs Features: uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Color Specifications (Per Light): Lumens: 1,581 Utilizing 2 LEDs Wattage/Amps: 12W / .9A Dimensions: 74.4mm (2.93″) x 44.7mm (1.76″) x 42.6mm (1.68″) Weight: 226.7g LED Life Expectancy: 49,930 Hours Front Lens: Hard Coated Polycarbonate Housing: Hard Anodized & Powder Coated Cast Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Overvoltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Contains: (2) LED Lights LED Holding Brackets (Not Engine bar clamps) Basic Wiring Harness ( Rel) Wiring harness has an inbuilt on/off switch ( With a SS bracket for installation – Refer image) Optional / Additional Upgrade available on request Longer Wiring Harness with Connectors and Push Button Switch Included Brackets 25mm (1″) or 22.2mm (7/8th Inch) ( engine Bar clamps) Included Patterns: Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42°) and spot (9°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) Available on Order:- Wide Cornering: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42° flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 & 2) Spot: A longer and narrower 9° beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 4 & 5) Flood: Excellent work light or “scene light” with an extremely smooth 60° circle that projects about 40ft. This pattern is not suitable for driving. (Lighting Zone 7) DATA SHEET Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” or any 30 days satisfaction guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – SQUADRON RACER

Squadron Racer Edition 4300 Lumens/pc – Spot Squadron Racer Racer Edition Baja Designs is proud to introduce the Squadron Racer, with 4,300 lumens. The Squadron Racer throws light an average of 40% further than the Squadron Pro with a High-intensity LED, housed in hard anodised and powder coat cast aluminium. Enjoy nearly 50,000 hours of bright, efficient lighting to enhance your nighttime off-roading experiences! As always, Baja Designs provides the best in auxiliary LED lights Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (40°) and spot (7°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) Baja Designs Features: Limited Lifetime Warranty uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Colour Specifications (Per Light): Lumens: 4,300 Utilising 4 High Intensity LEDs Wattage/Amps: 40W / 3.33A Dimensions: 77.9mm x 70.3mm x 77.9mm (3.07″ x 2.77″ x 3.07″) Weight: 340g LED Life Expectancy: 49,930 Hours Front Lens: Hardccoated Polycarbonate Housing: Hard Anodized & Powder Coated Cast Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Overvoltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Contains: (2) LED Lights LED Holding Brackets (Not Engine bar clamps) Basic Wiring Harness ( no relay or fuse) Wiring harness has an inbuilt on/off switch ( Does not mount a handlebar – Refer image) Optional / Additional Upgrade available on request Longer Wiring Harness with Connectors and Push Button Switch Included Brackets 25mm (1″) or 22.2mm (7/8th Inch) ( engine Bar clamps) Included Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – SQUADRON SAE

Baja Designs next generation Squadron® SAE. Engineered with all-new aspheric projector optics and with our advanced LED technology provides a performance increase in luminous flux of 56% over our previous generation SAE model. The all-new Squadron® SAE delivers 2,420 lumens per light with output reaching up to 15,800 candela 29 watts Keeping you safe on the road or trails, the Squadron® SAE will illuminate Zone 1 with a controlled, sharp cutoff from the combination of the new LED technology and highly efficient aspheric projector optics. Designed to meet the current SAE J583 fog lamp requirements, the Squadron® SAE is fully compliant with on-road regulations. This innovative approach allows for a highly controlled light pattern with a sharp cutoff, making them an ideal choice for driving through dust, fog, and inclement weather. ClearView – All The Light, Right Where You Need It MoistureBlock – Waterproof, Rain Proof, Submersible CopperDrive – Only LED Driven At 100 Percent 5000K Daylight – Less Driver Fatigue, Natural Color NOTE: uService® is NOT a feature of SAE products. If tampered, it will void the warranty. Dimensions per lights Depth (cm) 7.04 Height (cm) 7.70 Length (cm) 7.70 Weight (g) 340 Specifications per light Amperage Rating (A) 2.1 Average Rated Life (hr.) 49930 Beam Pattern SAE Fog Bezel Material Billet Machined Aluminum Brightness (Lumens) 2420 Description SAE Fog; Clear; Pair Housing Color Black Housing Material Hard Anodized and Powder Coated Cast Aluminum Lens Color Clear Lens Material Hardcoated Polycarbonate Light Quantity 2 Lighting Modes Beam Lighting Quantity 4 Lighting Technology Forward Projecting Lighting Type Cree LED Mounting Hardware Included Yes Mounting Hardware Material Stainless Steel Overvoltage Protection Built-In Product Type Squadron SAE LED Light Pod Pair w/ Wiring Harness Standards & Compliance Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable) Standards/Compliance (SAE) SAE Standard J583 Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – XL PRO

XL Pro LED Driving/Combo Patterns: Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (44°) and spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) Manual Specifications: Lumens: 4,900 Utilizing 4 Cree XP-L LEDs Wattage/Amps: 40W / 3.33A Dimensions: 133mm x 92.7mm x 133mm (5.24″ x 3.65″ x 5.24″) Weight: 1111g LED Life Expectancy: 49,930 Hours Front Lens: Hard coated Polycarbonate Housing: Hard Anodized & Powder Coated Cast Aluminum Bezel: Billet Machined Aluminum Hardware & Bracket Material: Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Over voltage Protection IP69K (Waterproof up to 2743mm (9ft) & Pressure Washable) IK10 Compliant (Mechanical Impact Testing) Includes: XL-R Pro LED Light Mounting Bracket Part Number:- BD Square Driving Combo 50 78-03 BD Square Speed Spot 50 78-01 BD Square Wide Beam 50 78-05 BD Round Driving Combo 53 78-03 BD Round Speed Spot 53 78-01 BD Round Wide Beam 53 78-05 DATA SHEET Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation

Aux LED – XL Racer

Two is always better than one, right? We think so, which is why we’re offering a pair of XL Racer Edition LED auxiliary lights with wiring harness. Baja Designs is proud to introduce the XL Racer, with 4,300 lumens per light. The XL Racer throws light an average of 40 percent further than the XL Pro with a High-intensity LED, housed in hard anodized and powder coat cast aluminum. Enjoy nearly 50,000 hours of bright, efficient lighting to enhance your nighttime off-roading experiences! The XL Racer Edition LED light utilizes our trademarked High Speed Spot reflectors providing for a longer beam pattern, and offers a 20 percent dimming feature. uService® – Replaceable Lenses And Optics ClearView® – All The Light, Right Where You Need It. MoistureBlockâ„¢ – Waterproof, Rain Proof, Submersible CopperDrive® – Only LED Driven At 100% 5000K Daylight – Less Driver Fatigue, Natural Color Dimensions: 112.5mm x 92.7mm x 112.5mm (4.43″ x 3.65″ x 4.43″) Weight: 1111g Amperage Rating (A) 3.300 Average Rated Life (hr.) 49,930 Beam Pattern Racer Edition Spot Bezel Material Billet Machined Aluminum Brightness (Lumens) 2800 Description Racer Edition Spot; Clear; Pair Housing Color Black Housing Material Hard Anodized and Powder Coated Cast Aluminum Lens Color Clear Lighting Modes Hardcoated Polycarbonate Light Quantity 2 Lens Material High Beam/Dimming Feature (20%) Lighting Quantity 4 Lighting Type High Intensity LED Lighting Technology Forward Projecting Mounting Hardware Included Yes Mounting Hardware Material Stainless Steel Overvoltage Protection Built-In Product Type XL80 Racer Edition LED Light Pod Pair w/ Wiring Harness Universal or Specific Universal Wattage (W) 45.540 Wiring Harness Included Yes Standards & Compliance Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing) Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing) Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable) Please note : Motousher does not offer any “Customer Satisfaction Guaranteed” nor any 30 days satisfaction guarantee, nor any money back guarantee of any sort as might be offered by Baja Designs. Motousher terms are clear and can be found at Terms and Conditions page

Key Features

• High-quality construction
• Durable
• Easy installation
